LIST OF ERROR MESSAGES, POSSIBLE CAUSES AND FIXES
ERROR MESSAGE POSSIBLE CAUSES FIXES
[Calibration error]
Obstruction on the gate rail during the
calibration procedure
Remove the obstruction and repeat the
calibration procedure
[The Encoder does not
work]
Encoder is disconnected or out-of-order Check connections or replace the motor
[Services test failed]
One or more obstructions detected by the
photocells
Remove any obstructions blocking the
photocell beams
Wrong connections or confi guration of the
photocells
Check the connections or the
confi guration
Photocell out-of-order Replace photocell
[Hatch is open] Operator is released Make sure the release hatch is closed.
[Maximum number of
closing obstructions]
There are one or more obstructions during
the closing maneuver
Remove obstructions
[Maximum number of
opening obstructions]
There are one or more obstructions during
opening maneuver
Remove obstructions
[Maximum number of
obstructions]
There are one more obstructions during
closing and opening maneuvers
Remove the obstructions
[Communication error]
The UTP CAT5 connection cable is
damaged
Check whether the cable is connected
and undamaged
Confi gured on the wrong RSE port
Check that the confi guration of the RSE
port is for "combined" on the MASTER
operator and CRO on the SLAVE
[Incompatible radio-
frequency control]
Non-CAME transmitters Use CAME transmitters
The coding settings are di erent to the
transmitter's
Make sure the radio is coded to match
the transmitters you are using
TWIN transmitters with di erent key block
Use TWIN transmitters that have the
same key block
[Slave hatch is open] SLAVE operator is released
Check that the release hatch is shut on
the operator.
[RIO system is
unreachable]
RIO module... not plugged into the
connector on the control board
Make sure the module is plugged in
RIO module ... out-of-order Replace the module
[RIO system not
confi gured]
RIO module ... is not confi gured with the
control board
Confi gure the RIO inputs to match the
control board
The RIO devices are not confi gured
Confi gure the devices (see corresponding
instructions for RIO accessories)
