CAME BKV Series User Manual

p. 6 - Manual FA01274-EN - 11/2018 - © CAME S.p.A. - The contents of this manual may change, at any time, and without notice. Original instructions
Limits to use
Type
BKV15AGS
BKV15ALS
BKV15AGE
BKV20AGS
BKV20ALS
BKV20AGE
BKV25AGS
BKV25ALS
BKV25AGE
BKV15RGS BKV20RGS
Maximum gate-leaf length (m) 20 20 20 20 20
Maximum gate-leaf weight (kg) 1.500 2.000 2.500 1.500 2.000
Pinion module 4 4 6 4 4
Technical data
Tipo
BKV15AGS
BKV15ALS
BKV15AGE
BKV20AGS
BKV20ALS
BKV20AGE
BKV25AGS
BKV25ALS
BKV25AGE
BKV15RGS BKV20RGS
Protection rating (IP) 44 44 44 44 44
Power supply (V - 50/60 Hz) 230 AC 230 AC 230 AC 120 AC 120 AC
Input voltage motor (V) 36 DC 36 DC 36 DC 36 DC 36 DC
Control board input voltage (V) 26 DC 26 DC 26 DC 26 DC 26 DC
Stand-by consumption (W) 14 14 14 14 14
Stand-by consumption with
the RGP1 (W) module
0.8 0.8 0.8 0.8 0.8
Maximum power (W) 200 250 300 200 250
Operating temperature (°C) -20 to +55 -20 to +55 -20 to +55 -20 to +55 -20 to +55
Thrust (N) 1200 1350 1500 1200 1350
Cycles/hour
CONTINUOUS
SERVICES
CONTINUOUS
SERVICES
CONTINUOUS
SERVICES
CONTINUOUS
SERVICES
CONTINUOUS
SERVICES
Maneuvering speed (m/min) 12 12 12 12 12
Acoustic pressure level (dB (A)) ≤70 ≤70 ≤70 ≤70 ≤70
Apparatus class I I I I I
Working time (s) 180 180 180 180 180
Weight (Kg) 20 21 21 20 21
