p. 33 - Manual FA01274-EN - 11/2018 - © CAME S.p.A. - The contents of this manual may change, at any time, and without notice. Original instructions
[AST control (run)] ➡ [Disabled] > [Minimun] > [Medium] > [Maximum] > [Costumize] (from 10%
maximum sensitivity to 100% sensitivity disabled).
To set the obstruction-detection sensitivity when the gate is motion.
[AST control (slowd.)] ➡ [Disabled] > [Minimun] > [Medium] > [Maximum] > [Costumize] (from 10%
maximum sensitivity to 100% sensitivity disabled).
Adjusting the obstruction detection sensitivity when the gate is slowing down.
[Slowed-down start] ➡ [O ] > [On]
Upon each opening and closing command. The gate starts slowly for some seconds.
[Partially open point] ➡ [10%] > ... > [100%]
To adjust the partial opening of the gate, calculated as a percentage of the total gate travel.
[Open slw-dwn point] ➡ [10%] > ... > [60%]
To adjust the point where the gate starts to slow down when opening, calculated as a percentage of the total
gate travel.
[Closing slow-down point] ➡ [10%] > ... > [60%]
To adjust the point where the gate starts to slow down when closing, calculated as a percentage of the total gate
travel.
Hard-wired safety devices
[Total Stop] function ➡ [O ] > [On]
NC input – Gate stop that excludes any automatic closing; to resume movement, use the control device. Plug the
device into contact 1-2.
[CX Input] ➡ [Disabled] > [C1] > [C2] > [C3] > [C4] > [C7] > [C8] > [C13] > [r7] > [r8] > [r7 (two sensitive
safety-edges)] > [r8 (two sensitive safety-edges)].
Input NC - Can associate: [C1] = reopening when closing by photocells, [C2] = reclosing when opening by
photocells, [C3] = partial stop, [C4] = obstruction wait, [C7] = reopening when closing by sensitive safety-
edges, [C8] = reclosing when opening by sensitive safety-edges, [C13] = , reopening when closing and with
immediate stop once the obstruction is removed even if the gate is stopped, [r7] = reopening during closing by
sensitive safety-edges (with 8k2 resistor), [r8] = reclosing during opening by sensitive safety-edges (with 8k2
resistor), [r7 (two sensitive safety-edges)] = reopening during closing by a pair of sensitive safety-edges (with
8k2 resistor), [r8 (two sensitive safety-edges)] = reclosing during opening by a pair of sensitive safety-edges
(with 8k2 resistor), [Disabled].
Function [C3] is enabled only if the [Automatic close] function is on.
⚠
Each time a change is made to the parameters of , the following , functions , , , [Opening speed],
Openingslow-down speed], [Closingslow-down speed], [Slowed-down start], [Opening slow-down point] and
[Closing slow-down point], the absorptions of either the fi rst opening or closing maneuver will be automatically
recorded. During this entire phase, the symbol on the top right of the display will remain visible.
Important! During the self-learning, check that the system is free of any obstructions.
Caution! During this phase, the obstruction detecting sensitivity is imprecise. Any obstruction simulations should
only be done when the warning symbol is no longer visible on the display
.
