CAME BKV Series User Manual

p. 29 - Manual FA01274-EN - 11/2018 - © CAME S.p.A. - The contents of this manual may change, at any time, and without notice. Original instructions
 The default parameters are in bold case
Main menu Level 2 menu Level 3 menu Parameters
Confi guration
Motor settings
Opening direction Left / Right
Motor test Press the < > keys
Gate-travel calibration Confi rm? NO / Confi rm? YES
Motor type BKV1500 / BKV2000 / BKV2500
Gate travel
settings
Opening speed 40% > ... > 100%
Closing speed 40% > ... > 100%
Opening slow-down speed 15% > ... > 50% > ... > 60%
Closing slow-down speed 15% > ... > 50% > ... > 60%
AST control (run)
Disabled / Minimum / Medium / Maximum /
Customize
AST control (slowd.)
Disabled / Minimum / Medium / Maximum /
Customize
Soft Start O / On
Part. open point 10% > ... > 20% > ... > 100%
Opening slow-down point 10% > ... > 25% > ... > 60%
Closing slow-down point 10% > ... > 25% > ... > 60%
Hard-wired
safety devices
Total Stop O / On
input CX
Disabled / C1 / C2 / C3 / C4 / C7 / C8
/ C13 / r7 / r8 / r7 (Two sensitive safety
edges) / r8 (Two sensitive safety edges)
CY input
Disabled / C1 / C2 / C3 / C4 / C7 / C8
/ C13 / r7 / r8 / r7 (Two sensitive safety
edges) / r8 (Two sensitive safety edges)
CZ input
Disabled / C1 / C2 / C3 / C4 / C7 / C8
/ C13 / r7 / r8 / r7 (Two sensitive safety
edges) / r8 (Two sensitive safety edges)
CK input
Disabled / C1 / C2 / C3 / C4 / C7 / C8
/ C13 / r7 / r8 / r7 (Two sensitive safety
edges) / r8 (Two sensitive safety edges)
Safety devices test On / O
Obstruction with motor
stopped
On / O
RIO safety
devices
RIO ED T1 Disabled / P0 / P7 / P8
RIO ED T2 Disabled / P0 / P7 / P8
RIO PH T1 Disabled / P1 / P2 / P3 / P4 / P13
RIO PH T2 Disabled / P1 / P2 / P3 / P4 / P13
Command inputs Command 2-7 Step by step / Sequential
Menu structure
