p. 9 - Manual FA01274-EN - 11/2018 - © CAME S.p.A. - The contents of this manual may change, at any time, and without notice. Original instructions
When operating at 230 V and outdoors, use H05RN-F-type cables that are 60245 IEC 57 (IEC) compliant;
whereas indoors, use H05VV-F-type cables that are 60227 IEC 53 (IEC) compliant. For power supplies up to 48
V, you can use FROR 20-22 II-type cables that comply with EN 50267-2-1 (CEI).
For combined connection and CRP, use a UTP CAT5-type cable (up to 1,000 m long).
If cable lengths differ from those specified in the table, establish the cable sections depending on the actual
power draw of the connected devices and according to the provisions of regulation CEI EN 60204-1.
For multiple, sequential loads along the same line, the dimensions on the table need to be recalculated
according to the actual power draw and distances. For connecting products that are not contemplated in this
manual, see the literature accompanying said products
C a b l e s f o r s t a n d a r d i n s t a l l a t i o n
CABLE LENGTH (m) < 2 0 f r o m 2 0 t o 3 0
Power-supply at 230 V AC 3G x 1.5 mm² 3G x 2.5 mm²
24 V AC - DC Flashing light 2 x 1 mm² 2 x 1 mm²
TX Photocells 2 x 0.5 mm² 2 x 0.5 mm²
RX photocells 4 x 0.5 mm² 4 x 0.5 mm²
Command and control devices *n° x 0.5 mm² *n° x 0.5 mm²
Antenna RG58 max 10 m
*n° = see product mounting instructions .
GENERAL INSTALLATION INDICATIONS
⚠
Only skilled, qualifi ed sta must install this product.
Preliminary checks
⚠
Before beginning the installation, do the following:
• check that the upper slide-guides are friction-free;
• make sure there is are opening and closing mechanical gate stops;
• make sure that the point where the gear motor is fastened is protected from any impacts and that the surface
is solid enough;
• set up suitable tubes and conduits for the electric cables to pass through, making sure they are protected from
any mechanical damage.
