Canon imagePROGRAF iPF830 User Manual

D Roll Paper Margin for Safety
You can specify the length of a margin on the leading edge of paper to ensure that paper susceptible to curling is
held firmly against the Platen.
•
E Near End Margin
Specify the length of the Near End Margin (the leading edge margin) of the roll, as needed.
Setting Item Details
Printer Default The setting of the control panel of the printer is applied.
3 mm (0.12 in) The document is printed in the standard size.
* Select this when you do not have any problems in printing.
20 mm (0.8 in) Select this when rubbing against the printhead occurs such as when using paper that
tends to curl.
F Cut Speed
Select the speed of automatic cutting, as needed. You can adjust this setting if paper is not cut well when automatic
cutting is used.
Setting Item Details
Printer Default The setting of the control panel of the printer is applied.
High Speed When the Standard setting does not result in cutting the surface cleanly, select this.
Standard Select this when you do not have any problems in automatic cutting.
Low Speed This helps prevent adhesive from sticking to the cutter and keeps the cutter sharp if you
select it when using adhesive paper.
G Mirror
Specify whether to print a mirror image, as needed. Select this option to print a version of the document or image
with the left and right sides inverted.
View Settings Dialog Box for the Printing Application
View Settings Dialog Box for the Printing Application
In the View Settings dialog box, you can check details of the selected printing application.
Note
•
To display the View Settings dialog box, on the Main sheet, click View Settings by Print Target. (See "Main
Sheet .") ➔P.154
• A
Print Target
Shows all Print Target options (settings items for the printing application).
• B
Name
Identifies the item selected in Print Target by its name and an icon.
iPF830
View Settings Dialog Box for the Printing Application
User's Guide
Windows Software Printer Driver
159

Canon imagePROGRAF iPF830 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	5
Page description languages	GARO, HP-GL/2, HP-RTL
Minimum line width	0.02 mm
Number of power supply units	1
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3az
Media thickness	0.07 - 0.8 mm
Maximum print size	A0 (841 x 1189 mm)
Maximum roll length	18 m
Media width (sheets)	1117.6 mm
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A0, A1
JIS B-series sizes (B0...B9)	B0, B2
Display	LCD
Product color	Black, Grey
Storage media	HDD
Internal storage capacity	320 GB
Sound power level (standby)	35 dB
Sound pressure level (printing)	52 dB
USB connector	USB Type-A
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet interface type	Gigabit Ethernet
Power supply	190 W
Power consumption (off)	0.5 W
Power consumption (standby)	5 W
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	975 mm
Width	1893 mm
Height	1144 mm
