Listed Jobs
Exports the data for the print jobs currently displayed in the list as a CSV file.
Displaying Job Properties or Period Properties
Displaying Job Properties or Period Properties
You can display the Job properties dialog box or Period Properties dialog box to check detailed cost information
and other items.
The Job properties dialog box displays detailed information about the selected job.
The Period Properties dialog box displays detailed information within the Regularly Acquired Jobs period.
Displaying the Job properties Dialog Box
Select a job from the job list, and then select Show Job Properties from Job properties in the File menu.
You can also select multiple jobs at once.
Note
You can also display the dialog box by selecting a job, right-clicking it, and then selecting Show Job Proper-
ties, or by using the icon in the toolbar.
Displaying the Period Properties Dialog Box
Select a period from the Regularly Acquired Jobs list, and then select Show Period Properties from Job
properties in the File menu. You can also select multiple periods at once.
Note
You can also display the dialog box by selecting and right-clicking a period and then selecting Show Period
Properties, or by using the icon in the toolbar.
Components of the Job properties Dialog Box/Period Properties Dialog Box
Job tab
Displays detailed information about the selected job. You can display detailed information about each job
by selecting the corresponding Document Name.
Owner tab
You can display detailed information about each owner by selecting the corresponding Owner.
Copy button
Click this button to copy the displayed text information to the clipboard.
iPF830
Displaying Job Properties or Period Properties
User's Guide
Print Job Management Accounting (Windows)
511

Table of Contents

Other manuals for Canon imagePROGRAF iPF830

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Canon imagePROGRAF iPF830 and is the answer not in the manual?

Canon imagePROGRAF iPF830 Specifications

General IconGeneral
ColorYes
Printing colorsBlack, Cyan, Magenta, Matte black, Yellow
Print technologyInkjet
Maximum resolution2400 x 1200 DPI
Number of print cartridges5
Page description languagesGARO, HP-GL/2, HP-RTL
Minimum line width0.02 mm
Number of power supply units1
Compliance industry standardsIEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3az
Media thickness0.07 - 0.8 mm
Maximum print sizeA0 (841 x 1189 mm)
Maximum roll length18 m
Media width (sheets)1117.6 mm
Maximum roll diameter150 mm
ISO A-series sizes (A0...A9)A0, A1
JIS B-series sizes (B0...B9)B0, B2
DisplayLCD
Product colorBlack, Grey
Storage mediaHDD
Internal storage capacity320 GB
Sound power level (standby)35 dB
Sound pressure level (printing)52 dB
USB connectorUSB Type-A
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet interface typeGigabit Ethernet
Power supply190 W
Power consumption (off)0.5 W
Power consumption (standby)5 W
Operating temperature (T-T)15 - 30 °C
Operating relative humidity (H-H)10 - 80 %
Sustainability certificatesENERGY STAR
Weight and Dimensions IconWeight and Dimensions
Depth975 mm
Width1893 mm
Height1144 mm
