View set. Dialog Box for the Printing Application
View set. Dialog Box for the Printing Application
In the View set. dialog box, you can check details of the selected printing application.
Note
• To display the View set. dialog box, on the Main pane, click View set. by Print Target. (See "Main
Pane .") ➔P.260
• A Print Target
Shows all Print Target options (settings items for the printing application).
• B Name
Identifies the item selected in Print Target by its name and an icon.
• C Details
Here, you can confirm detailed settings values for each item selected in the Print Target list.
Matching pane
Matching pane
On the Matching pane, you can specify color matching to compensate for differences in the appearance of colors
on various devices.
Important
•
The Matching pane is not displayed when No color correction or Monochrome is selected in Color Mode.
Note
• To display the Matching pane, on the Main pane click Color Settings by Color Mode in Advanced Settings, and
then click the Matching tab. (See "Main Pane .") ➔P.260
View set. Dialog Box for the Printing Application iPF830
User's Guide
Mac OS Software Printer Driver
266

Canon imagePROGRAF iPF830 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	5
Page description languages	GARO, HP-GL/2, HP-RTL
Minimum line width	0.02 mm
Number of power supply units	1
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3az
Media thickness	0.07 - 0.8 mm
Maximum print size	A0 (841 x 1189 mm)
Maximum roll length	18 m
Media width (sheets)	1117.6 mm
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A0, A1
JIS B-series sizes (B0...B9)	B0, B2
Display	LCD
Product color	Black, Grey
Storage media	HDD
Internal storage capacity	320 GB
Sound power level (standby)	35 dB
Sound pressure level (printing)	52 dB
USB connector	USB Type-A
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet interface type	Gigabit Ethernet
Power supply	190 W
Power consumption (off)	0.5 W
Power consumption (standby)	5 W
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	975 mm
Width	1893 mm
Height	1144 mm
