Back
Back
a
Carrying Handles
When carrying the printer, have six people hold it by these handles under both sides.
b
USB Port
Connect a USB cable to this port. The printer is compatible with Hi-Speed USB connections.
c
Ethernet Port
Connect an Ethernet cable to this port. The lamp is lit if the Ethernet cable is connected correctly and commu-
nication is possible between the computer and printer.
d
Manual Pocket
Store printer manuals in this pocket.
e
Accessory Pocket
Store assembly tools, Roll Holder attachments, and other items in this pocket.
f
Power Supply Connector
Connect the power cord to this connector.
g
Media Take-up Unit Power Inlet
Connect the connection cable for the Media Take-up Unit (optional).
Back
iPF830
User's Guide
Printer Parts Printer parts
464
