• C Enlarged/Reduced Printing
Choose from the following options when this setting is activated.
• Resizing Originals to Match the Paper Size ➔ P.60
• Resizing Originals to Fit the Roll Width ➔ P.62
• Resizing Originals by Entering a Scaling Value ➔P.66
• D Fit Paper Size
Scales the document image to match the paper size.
• E Fit Roll Paper Width
Scales the document image to match the roll width.
• F Scaling
Resizes the document image based on a specified scaling value. Enter a value in a range of 5–600.
• G Paper Size
Choose the size of the paper you will print on.
For details on available paper sizes, see "Paper Sizes." ➔ P.320
• H Orientation
Choose the printing orientation.
• Making the Original Orientation Match the Paper Orientation ➔ P.136
• K Rotate Page 90 degrees (Conserve Paper)
Activate this setting to rotate the document image by 90 degrees before printing.
• Conserving Roll Paper by Rotating Originals 90 Degrees ➔ P.125
• L Paper Source
Choose the feed source, as desired.
Options displayed in the list vary depending on the selection in Media Type on the Main sheet.
• M Roll Paper Width
Choose the roll width.
For details on available roll widths, see "Paper Sizes." ➔ P.320
• N
Roll Paper Options
Complete optional roll paper settings. Click to display the Roll Paper Options dialog box.
Under A Automatic Cutting, you can specify Yes or No and Print Cut Guideline.
• Cutting Roll Paper After Printing ➔ P.140
Select B Banner Printing when printing multiple pages continuously.
• Printing Multiple Pages Continuously ➔ P.106
Page Setup Sheet
iPF830
User's Guide
Windows Software Printer Driver
166

Canon imagePROGRAF iPF830 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	5
Page description languages	GARO, HP-GL/2, HP-RTL
Minimum line width	0.02 mm
Number of power supply units	1
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3az
Media thickness	0.07 - 0.8 mm
Maximum print size	A0 (841 x 1189 mm)
Maximum roll length	18 m
Media width (sheets)	1117.6 mm
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A0, A1
JIS B-series sizes (B0...B9)	B0, B2
Display	LCD
Product color	Black, Grey
Storage media	HDD
Internal storage capacity	320 GB
Sound power level (standby)	35 dB
Sound pressure level (printing)	52 dB
USB connector	USB Type-A
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet interface type	Gigabit Ethernet
Power supply	190 W
Power consumption (off)	0.5 W
Power consumption (standby)	5 W
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	975 mm
Width	1893 mm
Height	1144 mm
