Canon imagePROGRAF iPF830 User Manual

7 Print the job.
When printing is finished, the printer will stop without cutting.
8
Holding the printed document to prevent it from dropping,
press the Cut button to cut the roll.
Manual (when using media that cannot be cut with the Cutter Unit )
Rewind paper by pressing
the OK button
Feed paper to the cut
position by pressing the
Feed button and cut
manually
PrintSelect Manual
Manual
Rose Wine
Rose Wine
Note
•
Once the following step has been performed, the procedure can be started from step 8 the next time.
• Printing the second and subsequent times
• Printing after replacing with the same type of paper
1
On the Tab Selection screen of the Control Panel, press ◀ or ▶ to
select the Paper tab ( ).
Note
•
If the Tab Selection screen is not displayed, press the Menu button.
2 Press the OK button. The Paper Menu is displayed.
3 Press ▲ or ▼ to select Paper Details, and then press the OK button.
4 Press ▲ or ▼ to select the type of paper, and then press the OK button.
5 Press ▲ or ▼ to select Cutting Mode, and then press the OK button.
6 Press ▲ or ▼ to select Manual, and then press the OK button.
7 When "Perform the detection of paper leading edge?" is displayed, select Perform(recommend).
8 Print the job.
The printer stops advancing the paper after printing.
Specifying the Cutting Method for Rolls iPF830
User's Guide
Handling and Use of Paper Handling rolls
346

Canon imagePROGRAF iPF830 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	5
Page description languages	GARO, HP-GL/2, HP-RTL
Minimum line width	0.02 mm
Number of power supply units	1
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3az
Media thickness	0.07 - 0.8 mm
Maximum print size	A0 (841 x 1189 mm)
Maximum roll length	18 m
Media width (sheets)	1117.6 mm
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A0, A1
JIS B-series sizes (B0...B9)	B0, B2
Display	LCD
Product color	Black, Grey
Storage media	HDD
Internal storage capacity	320 GB
Sound power level (standby)	35 dB
Sound pressure level (printing)	52 dB
USB connector	USB Type-A
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet interface type	Gigabit Ethernet
Power supply	190 W
Power consumption (off)	0.5 W
Power consumption (standby)	5 W
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	975 mm
Width	1893 mm
Height	1144 mm
