Canon imagePROGRAF iPF830 User Manual

2 Press the OK button. The Paper Menu is displayed.
3 Press ▲ or ▼ to select Paper Details, and then press the OK button.
4 Press ▲ or ▼ to select the type of paper, and then press the OK button.
5 Press ▲ or ▼ to select Cutting Mode, and then press the OK button.
6 Press ▲ or ▼ to select Manual, and then press the OK button.
7
When "Perform the detection of paper leading edge?" is displayed, select Do not perform.
Note
•
If you set the detection of paper leading edge to Do not perform, a margin of about 10 cm is created at
the paper leading edge when printing starts.
• When the detection of paper leading edge is set to Do not perform, printing will start at the position at
which the roll was set for the first printing after replacing a roll. Thus, the margin of the paper leading edge
will enlarge.
(See "Loading Rolls in the Printer.") ➔P.333
8
Press the Feed button.
9
Press ▲ or ▼ to align the paper leading edge with
the (a) position.
10 Print the job.
The printer stops advancing the paper after printing.
Note
•
The printer can continue to receive print jobs from computers. If a print job is received and printed here, it
can be printed without the margin of about 10 cm being created at the paper leading edge.
11
Press the Feed button.
Roll paper is fed to the specified cut position and then auto-
matically stopped.
Specifying the Cutting Method for Rolls iPF830
User's Guide
Handling and Use of Paper Handling rolls
348

Canon imagePROGRAF iPF830 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	5
Page description languages	GARO, HP-GL/2, HP-RTL
Minimum line width	0.02 mm
Number of power supply units	1
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3az
Media thickness	0.07 - 0.8 mm
Maximum print size	A0 (841 x 1189 mm)
Maximum roll length	18 m
Media width (sheets)	1117.6 mm
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A0, A1
JIS B-series sizes (B0...B9)	B0, B2
Display	LCD
Product color	Black, Grey
Storage media	HDD
Internal storage capacity	320 GB
Sound power level (standby)	35 dB
Sound pressure level (printing)	52 dB
USB connector	USB Type-A
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet interface type	Gigabit Ethernet
Power supply	190 W
Power consumption (off)	0.5 W
Power consumption (standby)	5 W
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	975 mm
Width	1893 mm
Height	1144 mm
