Canon imagePROGRAF iPF830 User Manual

3
Select the paper in the Media Type list for which to
change the display order, and then click the buttons
to move the item ( or ).
The selected item moves one line up or down for ev-
ery button click.
4
In the Edit Media Types dialog box, click the Update
button.
5
The Confirm Update dialog box is displayed.
Configure Update Target and click the Execute but-
ton.
The printer control panel and printer driver media in-
formation is updated.
Note
•
You should normally select Update the printer control panel and printer driver.
Important
• When setting a data to the printer that differs from the data to be updated, the selected media informa-
tion file is updated. When you would like to remain the data that is set to the printer, click the Cancel
button.
6
The message on the right is displayed.
If you want to save the current media information in a file,
click the Yes button. If you do not want to save it, click the
No button.
Note
•
The media information is saved as a media information file (.amx file).
• For the method for loading a saved media information file in another computer, see "Applying a Saved
Media Information File on Another Computer." ➔P.395
Changing the Display Order of Media Types iPF830
User's Guide
Handling and Use of Paper Media Configuration Tool (Windows)
394

Canon imagePROGRAF iPF830 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	5
Page description languages	GARO, HP-GL/2, HP-RTL
Minimum line width	0.02 mm
Number of power supply units	1
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3az
Media thickness	0.07 - 0.8 mm
Maximum print size	A0 (841 x 1189 mm)
Maximum roll length	18 m
Media width (sheets)	1117.6 mm
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A0, A1
JIS B-series sizes (B0...B9)	B0, B2
Display	LCD
Product color	Black, Grey
Storage media	HDD
Internal storage capacity	320 GB
Sound power level (standby)	35 dB
Sound pressure level (printing)	52 dB
USB connector	USB Type-A
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet interface type	Gigabit Ethernet
Power supply	190 W
Power consumption (off)	0.5 W
Power consumption (standby)	5 W
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	975 mm
Width	1893 mm
Height	1144 mm
