• ▼ button
Press this button in the menu to move to another item.
In menu items requiring numerical input, press this button to decrement the number.
f OK button
Press this button on the Tab Selection screen to display the menu of the tab shown.
Pressing this button in menu items of each tab for which is displayed at left will move to the lower level of
the menu item, enabling you to execute menu commands or set menu values.
Also press this button if the Display Screen indicates to press the OK button.
g
Stop button
Cancels print jobs in progress and ends the ink drying period.
h Power button (green)
Turns the printer on and off. (See "Turning the Printer On and Off.") ➔P.17
The Power button is lit when the printer is on or in Sleep mode.
i Navigate button
Enables you to check instructions for loading and removing paper or replacing ink tanks or printheads, as well
as other operations. (See "How to View Instructions With Navigate.") ➔P.428
j Back button
Displays the screen before the current screen.
k Cut button
Pressing this button when rolls are loaded cuts the paper, if you have specified Automatic or Eject in Cutting
Mode in the Control Panel menu. (See "Specifying the Cutting Method for Rolls.") ➔ P.344
l Feed button
Pressing this button when rolls are loaded enables you to reposition the paper. (See "Feeding Roll Paper
Manually.") ➔ P.341
m
Load button
Press this button when loading or replacing paper.
(See "Loading Rolls in the Printer.") ➔ P.333
(See "Loading Sheets in the Printer.") ➔ P.353
n Roll Media lamp (green)
Lit when rolls are selected as the paper source.
o Cut Sheet lamp (green)
Lit when sheets are selected as the paper source.
Note
•
In Sleep mode, any button can be pressed except the Power button to recover from Sleep mode.
iPF830 Control Panel
User's Guide
Control Panel Operations and Display Screen
423

Canon imagePROGRAF iPF830 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	5
Page description languages	GARO, HP-GL/2, HP-RTL
Minimum line width	0.02 mm
Number of power supply units	1
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3az
Media thickness	0.07 - 0.8 mm
Maximum print size	A0 (841 x 1189 mm)
Maximum roll length	18 m
Media width (sheets)	1117.6 mm
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A0, A1
JIS B-series sizes (B0...B9)	B0, B2
Display	LCD
Product color	Black, Grey
Storage media	HDD
Internal storage capacity	320 GB
Sound power level (standby)	35 dB
Sound pressure level (printing)	52 dB
USB connector	USB Type-A
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet interface type	Gigabit Ethernet
Power supply	190 W
Power consumption (off)	0.5 W
Power consumption (standby)	5 W
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	975 mm
Width	1893 mm
Height	1144 mm
