2
Open the Top Cover and lift the Ejection Guide.
3
Remove the four ejection supports and lower the Ejection
Guide.
4
Grasp the Belt, insert it between the Belt Stopper, and affix
the Belt Stopper with a hex screw at the position indicated.
Preparing to Transfer the Printer
iPF830
User's Guide
Maintenance and Consumables Other Maintenance
598
