Note
• The job name when printing the adjustment pattern is "Original Image Name + Pattern-Print". For example, the print job
name for the image "ABC.jpg" is "ABC_Pattern-Print.jpg".
Paper Detailed Settings Dialog Box
Paper Detailed Settings Dialog Box
This dialog box appears when you click the Advanced Settings button on the Main Sheet. You can set Drying Time
and Roll Paper Margin for Safety by media type.
•
Drying Time
Between Pages
This sets the wait time for the ink to dry between each completely printed sheet and the output of the sheet.
Setting Details
Printer Default The settings of the printer operating panel are applied.
None The paper is ejected immediately after printing.
30sec. / 1min. / 3min. / 5min. /
10min. / 30min. / 60min.
The sheet is ejected when the specified time after printing has elapsed.
Between Scans
This sets the wait time between line scans during printing.
Setting Details
Printer Default The settings of the printer operating panel are applied.
None The printing continues to the next line immediately after the last line.
1sec. / 3sec. / 5sec. / 7sec. / 9sec. The printing continues to the next line after the set time.
*For the media type that has problems, such as ink smears on the page or colors that seem un-
even during borderless printing etc., increase the value for this setting.
•
Roll Paper Margin for Safety
Near End Margin
This sets the length of the near end margin of the roll paper.
Setting Details
Printer Default The settings of the printer operating panel are applied.
5mm Print at a standard size.
*Select for Media Type that has no problem when printing with a standard size margin.
20mm Select this when rubbing against the printhead occurs such as when using paper that tends to
curl.
•
Cut Speed
This selects the auto cut speed.
Paper Detailed Settings Dialog Box
iPF9400
User's Guide
Windows Software Print Plug-In for Photoshop / Digital Photo Professional
274
