Page #809 background imageLoading...
Page #809 background image
8
Examine test pattern A for adjustment. Determine the
pattern in which banding is least noticeable.
Note
If banding seems least noticeable in two patterns but you cannot decide which one is better, choose an intermediate
value.
For example, choose 11 if you cannot decide whether pattern 10 or 12 is better.
9
Press
or to select the pattern number you have decided, and then press the OK button.
Test pattern B is printed for adjustment.
Note
If you printed test pattern A on a sheet, follow the instructions on the Display Screen and use another sheet of the
same type of paper.
Additionally, after test pattern B is printed, follow the instructions on the Display Screen and remove the sheet.
10
Examine test pattern B for adjustment. Determine the pattern in which banding is least noticeable.
11
Press or to select the pattern number you have decided, and then press the OK button.
The adjustment value is now registered, and adjustment is complete.
Fine-Tuning the Paper Feed Amount
Fine-Tuning the Paper Feed Amount
If the contrast is uneven or banding in different colors appears at 50 mm (2.0 in) intervals in printed documents, try
executing Adj. Fine Feed during printing to fine-tune the feed amount.
Note
The Adj. Fine Feed menu is only displayed during printing.
Additionally, it is displayed when you have selected Automatic or Print Quality in Adj. Priority in Feed Priority.
(See "Menu Structure.") →P.661
Always execute Adj. Quality before Adj. Fine Feed.
Once you execute Adj. Quality, the Adj. Fine Feed value will revert to 0.
(See "Automatic Banding Adjustment.") →P.806
(See "Manual Banding Adjustment.") →P.807
Perform adjustment as follows.
1
On the Tab Selection screen of the Control Panel, press or to se-
lect the Settings/Adj. tab (
).
Note
If the Tab Selection screen is not displayed, press the Menu button.
2
Press the OK button.
The Set./Adj. Menu is displayed.
iPF9400
Fine-Tuning the Paper Feed Amount
User's Guide
Adjustments for Better Print Quality Adjusting the feed amount
809
