Enter the width of the media size.
Height
Enter the height of the media size.
•
Add button
Click the button to register the contents of the settings.
Curves Dialog Box
Curves Dialog Box
This dialog box appears when you click the Curves button on the Color Settings Sheet. You can set Channel and
other settings.
•
Channel
Select from among RGB, Red, Green, or Blue.
Note
• Gray is displayed for monochrome printing and this selection cannot be changed.
•
Input
Enter an input value.
Note
• The allowed entry range is 0 to 255.
• You can change the numbers by clicking either ▲ button or ▼ button.
•
Output
Enter an output value.
Note
• The allowed entry range is 0 to 255.
• You can change the numbers by clicking either ▲ button or ▼ button.
•
Load Curves button
Click the button to load stored data for a tone curve.
iPF9400
Curves Dialog Box
User's Guide
Windows Software Print Plug-In for Photoshop / Digital Photo Professional
279
