Canon imagePROGRAF iPF9400 User Manual

• Rotate
When you place a checkmark here, you can select Rotate Right or Rotate Left.
Setting Details
Rotate Right Rotates the object 90 degrees clockwise.
Rotate Left Rotates the object 90 degrees counterclockwise.
Note
• When several objects are selected, you cannot select Rotate.
•
Scaling
You can input the value for enlargement or reduction of the obeject in numerical characters.
Note
• You can input between 25 and 400.
• You can change the numbers by clicking either ▲ button or ▼ button.
•
Object Size
You can confirm the object size.
Note
• When several objects are selected, you cannot display Object Size.
Laying out a Multiple-File Document on One Page
Laying out a Multiple-File Document on One Page
You can lay out and print a multiple-file document on one page.
1 From the application software's File menu, select the printer setup menu to open the Print dialog box.
Note
• Normally, select Print from the File menu.
2 Click on Free Layout in the Page Setup panel to attach a checkmark.
3 In the Print dialog box, select the pages to print and the number of copies, and click the Print button.
Free Layout starts, laying out the document created with application software in the layout area as an object.
4 Leaving Free Layout running, open other files with the application software and repeat the above steps.
Laying out a Document Created with Multiple Application Programs on One Page
Laying out a Document Created with Multiple Application Programs on One Page
You can lay out and print a document created with multiple application programs on one page.
1 From the application software's File menu, select the printer setup menu to open the Print dialog box.
Note
• Normally, select Print from the File menu.
2 Click on Free Layout in the Page Setup panel to attach a checkmark.
3 In the Print dialog box, select the pages to print and the number of copies, and click the Print button.
Free Layout starts, laying out the document created with application software in the layout area as an object.
4 Leaving Free Layout running, open the files with other application software and repeat the above steps.
Laying out a Multiple-File Document on One Page (Mac OS X)
iPF9400
User's Guide
Mac OS X Software Free Layout
434

Canon imagePROGRAF iPF9400 Specifications

General

Color	Yes
Printing colors	Black, Matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Page description languages	GARO
Bundled software	Canon Printer Driver, Print Plug-in for Adobe Photoshop. Print Plug-in for Digital Photo Professional, Printer Driver Extra Kit (Free Layout, Color imageRUNNER Enlargement Copy, Advanced Preview), Print Plug-in for Microsoft® Word/Excel/PowerPoint (PC only), Accounting Manager, Gallery Wrap Feature
Media thickness	0.07 – 0.8 mm
Maximum print size	A0 (841 x 1189 mm)
Maximum roll length	18 m
Media width (rolls)	254 - 1524 mm
Media width (sheets)	203.2 - 1524 mm
Maximum roll diameter	150 mm
Storage media	HDD
Internal storage capacity	250 GB
Sound power level (standby)	35 dB
Sound pressure level (printing)	68 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet interface type	Gigabit Ethernet
Power consumption (off)	5 W
Power consumption (standby)	6 W
Power consumption (typical)	190 W
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	766 mm
Width	2299 mm
Height	1144 mm
