Adjustment for high-precision printing
Adjustment for high-precision printing
Enhancing Printing Quality
Enhancing Printing Quality
With some types of paper and under some conditions, adjusting the printer as follows with the paper to be used can
enhance printing quality when printing fine lines/text or photos.
Two adjustment options are available: standard adjustment (with the Printhead height set to Automatic) and supple-
mental adjustment (used if standard adjustment is not effective).
Important
• Ideal temperature and humidity during adjustment and for printing in general when the Printhead height is set to Automatic
are 20–30ºC and 30–60%. Under other environmental conditions, adjustment may not enhance printing quality.
Standard Adjustment
Perform standard adjustment with the Printhead height set to Automatic.
1 Load paper in the printer.
• Attaching the Roll Holder to Rolls →P.530
• Loading Rolls in the Printer →P.533
2 On the Tab Selection screen of the Control Panel, press ◀ or ▶ to select the Settings/Adj. tab ( ).
Note
• If the Tab Selection screen is not displayed, press the Menu button.
3 Press the OK button.
The Set./Adj. Menu is displayed.
4 Press ▲ or ▼ to select Adjust Printer, and then press the OK button.
5 Press ▲ or ▼ to select Head Posi. Adj., and then press the OK button.
6 Press ▲ or ▼ to select Standard, and then press the OK button.
A test pattern is printed for adjustment. This process will take about 13 minutes.
Note
• If standard adjustment does not enhance printing quality, next try supplemental adjustment, which may be helpful.
Supplemental Adjustment
Perform supplemental adjustment with the Printhead height set to Super Low.
Important
• Printing with Head Height set to Super Low may enhance printing quality, but it may also cause paper to rub against or
become caught on the Printhead, which may cause paper jams or soiling on printed documents.
Note
• We recommend that additional adjustment be executed using paper matching the following criteria.
Type: Glossy or semi-glossy photo paper, or proofing paper (in either case, roll paper only)
Thickness/weight: 300 μm or less, or 300 g/m² or less
Width: 420.0 mm (16.54 in.) or more
Enhancing Printing Quality iPF9400
User's Guide
Adjustments for Better Print Quality Adjustment for high-precision printing
796

Canon imagePROGRAF iPF9400 Specifications

General

Color	Yes
Printing colors	Black, Matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Page description languages	GARO
Bundled software	Canon Printer Driver, Print Plug-in for Adobe Photoshop. Print Plug-in for Digital Photo Professional, Printer Driver Extra Kit (Free Layout, Color imageRUNNER Enlargement Copy, Advanced Preview), Print Plug-in for Microsoft® Word/Excel/PowerPoint (PC only), Accounting Manager, Gallery Wrap Feature
Media thickness	0.07 – 0.8 mm
Maximum print size	A0 (841 x 1189 mm)
Maximum roll length	18 m
Media width (rolls)	254 - 1524 mm
Media width (sheets)	203.2 - 1524 mm
Maximum roll diameter	150 mm
Storage media	HDD
Internal storage capacity	250 GB
Sound power level (standby)	35 dB
Sound pressure level (printing)	68 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet interface type	Gigabit Ethernet
Power consumption (off)	5 W
Power consumption (standby)	6 W
Power consumption (typical)	190 W
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	766 mm
Width	2299 mm
Height	1144 mm
