Print Quality (*1) Description Print Priority
High Choose this setting to print at high resolution when
quality is most important.
Printing takes longer and consumes more ink than in
Standard or Fast modes, but this mode offers excep-
tional printing quality.
Line Drawing/Text
Proof
Standard Choose this setting to print at standard resolution
when quality and speed are both important.
Printing takes less time than in Highest or High
mode.
Line Drawing/Text
Office Document
Proof
Fast Choose this setting to print faster.
Printing in draft mode can help you work more effi-
ciently when checking layouts.
Line Drawing/Text
*1: Options suitable for the selected Print Priority are listed under Print Quality.
•
Color Settings
Setting Item Options Description
Color Mode (*1) Color
Monochrome (Photo)
Monochrome
No color correction
Choose whether to print in color or mono-
chrome.
(Refer to "Adjusting the Color in the Printer
Driver →P.54 ")
Color Adjustment (Images) Cyan
Magenta
Yellow
Gray Tone
Brightness
Contrast
Saturation
You can adjust the levels of cyan, magenta,
and yellow as well as the brightness, con-
trast, saturation, and gray tone separately for
images, graphics, and text documents.
If you choose Monochrome in Color Mode
only Brightness and Contrast can be adjus-
ted.
Color Adjustment (Graphics)
Color Adjustment (Text)
Gray Adjustment Color Balance
Brightness
Contrast
Highlight
Shadow
Choose the gray tone color balance ( Cool
Black or Warm Black) and adjust levels of
brightness, contrast, highlight, and shadow as
desired.
These levels can be adjusted when Mono-
chrome (Photo) is selected in Color Mode.
Color-Matching Modes Driver Matching Mode
ICC Matching Mode
Choose the color-matching mode. Other col-
or-matching modes may be provided by the
computer operating system, such as ICM and
ColorSync.
Color-Matching Method (*2) Auto
Perceptual
Saturation
Monitor Matching
Colorimetric
other
Choose the color-matching method. The
available options vary depending on your se-
lection in Color-Matching Mode.
Color Space (*3) sRGB
Adobe RGB
Choose a standard color space ( sRGB) or
an expanded color space ( Adobe RGB).
*1: Options suitable for the selected
Print Priority and Media Type are listed under Color Mode.
*2: The order of options displayed varies depending on the operating system.
*3: Adobe RGB is not available if an incompatible combination of the paper type and print quality is selected.
•
Enhancing printing quality
Setting Item Description
Thicken Fine Lines Prints making fine lines appear thicker.
Giving Priority to Particular Graphic Elements and Colors for Printing
iPF9400
User's Guide
Enhanced Printing Options Adjusting Images
62
