6
Load the custom paper in the printer and then click the
OK button.
Important
• Do not load paper that is curled or that has already been printed on.
7
The Step 3: Paper Source Settings dialog box is dis-
played. Select the paper source where the custom pa-
per is loaded and then click the OK button.
8
The Step 4: Paper feed adjustment dialog box is dis-
played. Click the Execute button to execute paper feed
adjustment.
The adjustment pattern is printed, and the paper feed is
automatically adjusted based on the printing result.
Once the paper feed adjustment is complete, click the
Next button.
Important
• Check that there is no paper left on the ejection guide.
• If Paper Feed Adjustment is not executed, horizontal stripes with different color tones may appear in the printed
material. Paper feed adjustment does not need to be executed more than once. Execute paper feed adjustment
only once each time you add a custom paper.
9
The Roll Paper Settings dialog box is displayed.
Note
• If a paper source other than Roll Paper is selected in the Step 3: Paper Source Settings dialog box, this screen is
not displayed.
iPF9400
Add Custom Paper (Mac OS X)
User's Guide
Handling and Use of Paper Media Configuration Tool (Mac OS X)
635
To Next Page
