Important
• This function is not available with CAD Tracing Paper, CAD Translucent Matte Film, or CAD Clear Film.
• If adjustment is not possible as expected using special media, try another type of paper, or try Manual adjustment.
(See "Manual Adjustment to Straighten Lines and Colors.") →P.800
Note
• Because the results of adjustment vary depending on the type of paper used for adjustment, use the same type of paper as
you will use for printing.
• If Standard does not improve printing, try adjusting the printhead manually.
(See "Manual Adjustment to Straighten Lines and Colors.") →P.800
• If the printhead position was not adjusted during initial setup or when the printhead was replaced, execute Initial adjustmt.
(See "Adjustment When Installing the Printhead.") →P.802
• Advanced adjustment can enable superior printing quality when printing fine lines or text at high precision on glossy or semi-
glossy photo or proofing paper.
(See "Enhancing Printing Quality.") →P.796
Items to Prepare
When Using Rolls An unused roll at least 254.0 mm (10.00 in) wide
When Using Sheets Standard : Six sheets of unused paper, A4/Letter size (or one sheet when using A2)
Simple : One sheet of unused paper, A4/Letter size
Perform adjustment as follows.
1
Load paper.
•
Attaching the Roll Holder to Rolls →P.530
•
Loading Rolls in the Printer →P.533
•
Loading Sheets in the Printer →P.555
Important
• Always make sure the loaded paper matches the type of paper specified on the printer. Adjustment cannot be com-
pleted correctly unless the loaded paper matches the settings.
2
On the Tab Selection screen of the Control Panel, press ◀ or ▶ to se-
lect the Settings/Adj. tab (
).
Note
• If the Tab Selection screen is not displayed, press the Menu button.
3
Press the OK button.
The Set./Adj. Menu is displayed.
iPF9400
Automatic Adjustment to Straighten Lines and Colors
User's Guide
Adjustments for Better Print Quality Adjusting the Printhead
799
To Next Page
