2
On the Tab Selection screen of the Control Panel, press ◀ or ▶ to se-
lect the Settings/Adj. tab (
).
Note
• If the Tab Selection screen is not displayed, press the Menu button.
3
Press the
OK button.
The Set./Adj. Menu is displayed.
4
Press ▲ or ▼ to select Adjust Printer, and then press the OK button.
5
Press ▲ or ▼ to select Head Posi. Adj., and then press the OK button.
6
Press ▲ or ▼ to select Other, and then press the OK button.
7
Press ▲ or ▼ to select Manual, and then press the OK button.
A test pattern is printed for adjustment.
Note
• Manual may be unavailable in some cases, even if it is displayed in the menu.
If so, execute Standard once.
(See "Automatic Adjustment to Straighten Lines and Colors.") →P.798
8
Press ▲ or ▼ to select D, and then press the OK button.
9
Press ▲ or ▼ to select D-1, and then press the OK button.
10
Examine adjustment test pattern D-1 and determine the number
with straight lines.
Note
• If two patterns seem equally good and you cannot decide which one is better, choose an intermediate value.
For example, choose 11 if you cannot decide whether pattern 10 or 12 is better.
11
Press ▲ or ▼ to select the pattern number you have decided, and then press the OK button.
12
Repeat steps 8–10 to specify the adjustment value for D-1 to D-36.
Note that D-6, D-18, and D-30 cannot be configured.
iPF9400
Manual Adjustment to Straighten Lines and Colors
User's Guide
Adjustments for Better Print Quality Adjusting the Printhead
801
To Next Page
