Canon imagePROGRAF iPF9400 User Manual

Caution
• For safety, keep the Printhead out of the reach of children.
• If ink is accidentally ingested, contact a physician immediately.
• Do not touch the Printhead immediately after printing. The Printhead becomes extremely hot, and there is a risk of burns.
Important
• There may be ink around the nozzles of the Printhead you remove. Handle the Printhead carefully during replacement. The
ink may stain clothing.
• Do not open the Printhead pouch until immediately before installation. After removing the Printhead from the pouch, install it
right away. If the Printhead is left after the pouch is opened, the nozzles may dry out, which may affect printing quality.
Access the menu for Printhead replacement
Caution
• When replacing the Printhead immediately after printing, wait a few minutes before replacing it. The metal parts of the Print-
head become hot during printing, and there is a risk of burns from touching these parts.
Important
• Your hands may become dirty during Printhead replacement. Use the gloves provided with the new Printhead for replace-
ment.
Note
• Prepare a new Ink Tank when ink levels are low.
• When the remaining capacity of Maintenance cartridge is low, prepare a new Maintenance cartridge.
1 Remove any paper that has been advanced by selecting Eject Paper in the Control Panel menu.
• When using a roll, rewind it.
(See "Removing the Roll from the Printer.") →P.539
• When using sheets, remove the sheet.
(See "Removing Sheets.") →P.560
2 Clean inside the Top Cover. (See "Cleaning Inside the Top Cover.") →P.861
3
On the Tab Selection screen of the Control Panel, press ◀ or ▶ to se-
lect the Settings/Adj. tab ( ).
Note
• If the Tab Selection screen is not displayed, press the Menu button.
4 Press the OK button.
The Set./Adj. Menu is displayed.
5 Press ▲ or ▼ to select Maintenance, and then press the OK button.
6 Press ▲ or ▼ to select Replace P.head, and then press the OK button.
7 Press ▲ or ▼ to select the Printhead for replacement.
Select Printhead L when replacing the left printhead, Printhead R when replacing the right printhead, and L &
R Printheads when replacing both. Make sure your selection is correct.
iPF9400 Replacing the Printhead
User's Guide
Maintenance and Consumables Printheads
841

Canon imagePROGRAF iPF9400 Specifications

General

Color	Yes
Printing colors	Black, Matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Page description languages	GARO
Bundled software	Canon Printer Driver, Print Plug-in for Adobe Photoshop. Print Plug-in for Digital Photo Professional, Printer Driver Extra Kit (Free Layout, Color imageRUNNER Enlargement Copy, Advanced Preview), Print Plug-in for Microsoft® Word/Excel/PowerPoint (PC only), Accounting Manager, Gallery Wrap Feature
Media thickness	0.07 – 0.8 mm
Maximum print size	A0 (841 x 1189 mm)
Maximum roll length	18 m
Media width (rolls)	254 - 1524 mm
Media width (sheets)	203.2 - 1524 mm
Maximum roll diameter	150 mm
Storage media	HDD
Internal storage capacity	250 GB
Sound power level (standby)	35 dB
Sound pressure level (printing)	68 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet interface type	Gigabit Ethernet
Power consumption (off)	5 W
Power consumption (standby)	6 W
Power consumption (typical)	190 W
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	766 mm
Width	2299 mm
Height	1144 mm
