COPYRIGHT
©
2000 CANON INC. 2000 2000 2000 2000 CANON iR5000/iR6000 REV.0 JULY 2000
CHAPTER 1 BASIC OPERATION
1-4 R
4. Inputs to and Outputs from the Major PCBs
4.1 Wiring of Major PCBs
Controller
unit
DC
controller
PCB
CCD/AP PCB
Scanner motor
Inverter PCB
Reader
controller
PCB
J5011
J5101
J5007
J5003
J5004
J6002
Note: The symbol in the diagram indicates the major wiring route, NOT the flow of signals.
M3
F01-401-01 Wiring of Major PCBs
