Canon iR5000 - Removing the Reader Rear Cover

COPYRIGHT © 2000 CANON INC. 2000 2000 2000 2000 CANON iR5000/iR6000 REV.0 JULY 2000
CHAPTER 3 IMAGE PROCESSING SYSTEM
3-11 R
4.2 Removing the Reader Rear Cover
1) Remove the five screws [1], and detach
the rear cover [2].
F03-402-01
[1]
[1]
[2]
