COPYRIGHT
©
2000 CANON INC. 2000 2000 2000 2000 CANON iR5000/iR6000 REV.0 JULY 2000
CHAPTER 3 STANDARDS AND ADJUSTMENTS
3-21 T
4.17 Attaching the Drive Belt
Attach the drive belt on the pulley and the rollers as indicated.
F03-417-01
Main drive belt
Paper feed
drive belt
