5. Drum Cleaner Unit
5.1 Outline
The following component parts are associated with the drum cleaner unit:
F04-501-01
Pre-exposure lamp (LED)
Cleaning blade
Separation claw
Magnet roller
Auxiliary roller
Waste toner
feedscrew
