COPYRIGHT
©
2000 CANON INC
.
2000 2000 2000 2000
CANON iR5000/iR6000 REV
.0 JUL
Y 2000
CHAPTER 2 ORIGINAL EXPOSURE SYSTEM
2-20 R
[11]
[12]
[13]
[10]
[11]
8)
Remov
e the two cable f
ixing scre
ws
[11] of the No. 1 mirror base [10].
9)
Remov
e the two springs [12] used to
secure the cable in place.
10)
Remov
e the cable f
ixing plate [13] and
each pulley cable.
F02-602-04
Download Free Service Manual at http://printer1.blogspot.com
