Canon MV750i E - MODE MI-COM A;D Port; MI-COM Input Port; MI-COM A;D Port

MV750i E, MV730i E, MV700i E, MV700 E, MV690 E
SERVICE MODE · ADJUSTMENT
11
4-6-2 MODE MI-COM A/D Port
4-6-3 FR MI-COM Input Port
4-6-4 FR MI-COM A/D Port
PIN NAME Description CS Function ADDR
AA16
ZOOMKEY Zoom key output 0 02 0002
TELE
side
WIDE
side
AC17
TEMP Lens thermometer output 0 02 0003
X15
Y GYRO YAW side GYRO output 0 02 0004
AB16
P GYRO PITH side GYRO output 0 02 0005
Y15
I ENC IRIS ENC output 0 02 0006 Small diaphragm Open
AA15
MSW AD Mechanical position 0 02 000A
AC15
DEW DEW detection 0 02 000B
Y14
CAS IN Cassette detection 0 02 000C
Cassette
inserted
Cassette
not inserted
AC14
WIDE DET Wide signal detection 0 02 000D
AA14
TAPE TOP Beginning detection 0 02 000E
AB14
TAPE END Ending detection 0 02 000F
AD DATA (00
〜
FF)
Intermediate
PIN NAME Description CS Function ADDR
95
KEY AD3 KEY AD 3 1 02 0000 MENU(00) SET(40)
93
KEY AD2 KEY AD 2 1 02 0001 STOP(00) PLAY(40) FF(85)
92
KEY AD1 KEY AD 1 1 02 0002 ON/OFF(00) DE(40) AE(85)
91
KEY AD0 KEY AD 0 1 02 0003 D.CODE(00) C.MIX(40) REW(85)
88
Batt Info A/D Battery Type Detection 1 02 0006
87
Batt A/D Battery Voltage Detection 1 02 0007 Low(00) High(FF)
No Battery(00
〜
33)
BP-535(34
〜
65)
BP-522(66
〜
99
）
BP-511/512/514(9A
〜
CD)
BP-508(CE
〜
FF)
AD DATA (00
〜
FF)
PIN NAME Description CS Function ADDR DATA BIT
P6
SDE T
S JACK det ect io n
0010000 5
W1
USB DET USB Detect 0 01 0009 5
X5
CARD DET CARD detection 0 01 0009 4
E3
REC PROOF Tape recording inhibition 0 01 000A 7
U6
CARD PRO Card recording inhibited 0 01 000A 2
