MV750i E, MV730i E, MV700i E, MV700 E, MV690 E
SERVICE MODE · ADJUSTMENT
24
5-7-2 C. FG Adjustment
MODE Playback of color bar master (DY9-1381-000)
SPEC. Automatic adjustment
Procedure)
(1) While playing back the color bar master, carry out C.FG automatic adjustment referring to the table shown below.
5-7-3 Automatic Adjustment of Reel FG
MODE Stop without VTR cassette
Procedure)
(1) Carry out reel FG adjustment according to the following table.
5-7-4 Flash Memory Writing
SPEC. Memory data writing
Procedure)
(1) Write adjustment data (5-7-0 to 3) into the flash memory according the table shown below.
STEP PROCEDURE MONITOR Microcomputer operation
C.FG(AUTO) CS Function MD ADDR DT
1 1) Make the setting shown at right. 0 08 ST 0003 --
2) Perform storing.
↑↑
WR
↑↑
Automatic adjustment is in progress.
(press the PAUSE button.)
↑↑
RD
↑↑
Automatic adjustment is completed.
STEP PROCEDURE MONITOR Microcomputer operation
CS Function MD ADDR DT
1 1) Make the setting shown at right. 0 08 ST 0007 --
2) Perform storing.
↑↑
WR
↑↑
Automatic adjustment is in progress.
(press the PAUSE button.)
↑↑
RD
↑↑
Automatic adjustment is completed.
STEP PROCEDURE Microcomputer operation
CS Function MD ADDR DT
1 1) Make the setting shown at right. 0 08 ST 0081 -- Preparation for flash memory updating.
2) Perform storing.
↑↑
RD
↑↑
Execution of flash memory updating.
(press the PAUSE button.)
MONITOR
