Canon MV750i E - 1-3 Current Consumption Check

MV750i E, MV730i E, MV700i E, MV700 E, MV690 E
SERVICE HINTS
4
1-3 Current Consumption Check
The following table shows the specified value of current consumption in each status.
Measurement condition : Product status, camera auto mode(AF OFF), LCD ON (Approx. 0.15A each smaller in case of CVF)
Preset voltage : 7.4V
POWER SW MODE Current consumption (A)
CAMERA REC PAUSE 0.41
REC 0.45
VCR STOP 0.33
PLAY 0.42
POWER OFF 0.3 (mA)
