Canon MV750i E - Separation of Accessory Shoe and Lithium Battery Cover

MV750i E, MV730i E, MV700i E, MV700 E, MV690 E
DISASSEMBLING
4
1-2 Separation of Accessory Shoe and Lithium Battery Cover
(1) Remove the Lithium Battery Cover.
(2) Remove four screws (a × 4), and detach the Accessory Shoe.
Fig. 1
3mm
Metal
M1.7
Flat Head Screw
a
(1)
(2)
(2) - a
Accessory Shoe
Lithium Battery Cover
