Canon MV750i E - 3-2 Operation at Charging

MV750i E, MV730i E, MV700i E, MV700 E, MV690 E
TECHNICAL DESCRIPTION
7
3-2 Operation at Charging
3-2-1 Conditions to Start Charging
When the following conditions are satisfied, the MODE MI-COM (IC100) starts charging.
Conditions Detection Source of detection
Main unit power is turned OFF. MODE MI-COM pin 76/77 POWER SW
Battery is installed. MODE MI-COM pin 88 Battery D terminal
(BATT INFO AD) (CN3202 pin 2)
DC JACK is inserted. MODE MI-COM pin 71 DC JACK
(DC JACK DET) (CN3201 pin 3)
DC JACK input voltage is 8.4±0.3V. MODE MI-COM pin 87
(BATT AD) DC JACK
MODE MI-COM pin 73 (CN3201 pin 2)
(UNREG DET)
