MV750i E, MV730i E, MV700i E, MV700 E, MV690 E
SERVICE MODE · ADJUSTMENT
23
5-7 Recorder Section Adjustment
Note)
(1) Each of the adjustment data (5-7-0 to 5-7-3) becomes valid when 5-7-4 flash memory writing is made. When turning power OFF/
ON during each adjustment, be sure to carry out 5-7-4 flash memory writing.
Preparation)
(1) Except for the tape-path adjustment, carry out adjustment in the product state.
5-7-0 Setting for Destination
SPEC. Automatic writing
Procedure)
(1) Referring to the table shown below, carry out the setting for destination market place.
Note) For only MV690 E, perform this adjustment. Do not perform for the other models.
5-7-1 SWP Adjustment
MODE Playback of color bar master (DY9-1381-000)
SPEC. Automatic adjustment
Procedure)
(1) While playing back the color bar master, carry out SWP automatic adjustment referring to the table shown below.
STEP PROCEDURE MONITOR Microcomputer operation
SWP (AUTO) CS Function MD ADDR DT
1 1) Make the setting shown at right. 0 08 ST 0001 --
2) Perform storing.
↑↑
WR
↑↑
Automatic adjustment is in progress.
(press the PAUSE button.)
↑↑
RD
↑↑
Automatic adjustment is completed.
STEP PROCEDURE Microcomputer operation
CS Function MD ADDR DT
1 1) Make the setting shown at right. 1 10 ST 014D 01 MV690 E ONLY
2) Perform storing.
↑↑
RD
↑↑
Data writing
(press the PAUSE button.)
MONITOR
To Next Page
