Canon MV750i E - Page 164

MV750i E, MV730i E, MV700i E, MV700 E, MV690 E
SERVICE HINTS
3
Fig. 3
CA P.C.B.
LCD P.C.B.
JACK2 P.C.B.
IC1002
TG/CDS/AGC/AD
IC4201
DC/DC CONVERTER CONTROL
IC903
LCD DRIVE
IC901
EEPROM
IC1602
Y SENSOR GYRO
IC1601
P SENSOR GYRO
IC1006
2.8V REGULATOR
IC1001
V-DRIVER
