13
MECHANICAL PARTS
SYMBOL PART NO. CLASS Q’TY DESCRIPTION REMARKS
MV750i E, MV730i E, MV700i E, MV700 E, MV690 E
PARTS LIST
1 XA1-7170-307 000 F 4 SCREW
2 DA3-1114-000 000 B 1 COVER, LCD TOP MV750i E NEW
DA3-1119-000 000 B 1 COVER, LCD TOP MV730i E NEW
DA3-1117-000 000 B 1 COVER, LCD TOP MV700i E NEW
DA3-1118-000 000 B 1 COVER, LCD TOP MV700 E NEW
DA3-1121-000 000 B 1 COVER, LCD TOP MV690 E NEW
3 DA3-1109-000 000 C 1 SPRING, LCD NEW
4 DY1-8640-000 000 C 1 PCB, ASS’Y, LCD NEW
5 DG3-0339-000 000 C 1 BACK LIGHT ASS’Y, LCD NEW
*1 6 DY1-8333-000 000 B 1 LCD ASS’Y
*2 WG2-5210-000 000 B 1 LCD ASS’Y
7 DA3-1108-000 000 C 1 HOLDER, LCD NEW
8 DA3-1122-000 000 C 1 SHEET, LCD NEW
9 DA3-1107-000 000 B 1 COVER, LCD BOTTOM NEW
10 DA3-1112-000 000 C 2 SHEET NEW
11 DA3-1110-000 000 B 1 COVER, HINGE TOP NEW
12 DG3-0338-000 000 C 1 HINGE ASS’Y, LCD NEW
13 DA3-1111-000 000 B 1 COVER, HINGE BOTTOM NEW
14 DY1-8638-000 000 C 1 FPC ASS’Y, LCD NEW
15 XA1-7170-257 000 F 3 SCREW
*1 : Free from the pixel dot.
*2 : Same quality as the production line.
