MV750i E, MV730i E, MV700i E, MV700 E, MV690 E
GENERAL DESCRIPTION OF PRODUCT
22
6-7-5 USB terminal (MV750i E, MV730i E only)
Complies with USB2.0 FullSpeed class
6-8 Output signals (MV750i E, MV730i E only)
6-8-1 DV terminal SD format signals complying with IEEE1394-AV/C protocol
6-8-2 AV terminal
a. Video signals
Types of signals PAL standard color video signals
Impedance 75 Ω
Signal level 1 Vp-p (composite)
Horizontal resolution
Self-recording/playback Approx. 430 TV lines (screen center)
Camera EE OUT Max. approx. 430 TV lines (screen center)
b. Audio signals
Types of signals Stereo audio signal
Impedance Min. 40 kΩ
Signal level −10 dBv
Frequency characteristic 60 Hz to 16 kHz (Range between 1 kHz standard ±3 dB)
Audio signal S/N
Built-in microphone input Min. 48 dB
External microphone input (No microphone terminal)
6-8-3 S-Video terminal (MV750i E model only)
Signal configuration PAL Y/C separated video signal
Video signals 1 Vp-p (brightness + synchronization signal)
Color signal 0.3 Vp-p (Color burst signal)
Impedance 75 Ω
Signal level 0.3 Vp-p (Color burst signal)
Brightness signal S/N Min. 45 dB
Horizontal resolution
Self recording / playback Conforms to camera EE OUT
Camera EE OUT Max. approx. 430 TV lines (screen center)
6-8-4 Headphone terminal φ 3.5 mm stereo mini jack
Output impedance 47 Ω
Signal level −25 dBv (with 16 Ω load at maximum volume)
6-8-5 USB terminal (MV750i E, MV730i E only)
Complies with USB2.0 FullSpeed class
USB device class Independent class, PTP class, mass storage class, audio class, video class
Compatible computer systems Windows : IBM PC/AT compatible, NEC PC98-NX Series
Macintosh: Power Macintosh, PowerBook, iMac, iBook
PC operating system Windows : Windows 98, Windows 98SE, Windows ME, Windows 2000, Windows XP
Macintosh: Mac OS 9 or later
6-9 Memory card system (MV750i E, MV730i E only)
6-9-1 Types of memory cards used SD memory card, Multimedia card
6-9-2 Recordable image types
a. Still image JPEG recording
In Camera mode When [CARD ] is selected for [PHOTO REC] on the [CAM SET UP] menu, still images can be
recorded on the memory card by operating the photo button while motion video is being re-
corded on the tape. (Tape simultaneous recording function : VGA still image)
In Card Recording mode Still image is recorded using the Photo button (image size and image quality are selectable).
Writing in Progress warning is displayed in the EVF / LCD.
In VCR mode Still image is recorded using the photo button during tape playback (pressed halfway down for
still image playback and pressed all the way down for recording). (VGA still images)
Also, DV input images (when no tape loaded or loaded tape is stopped) can be recorded by
pressing the photo button (pressing halfway captures still image of the DV input, pressing all the
way down records the image).
