Appendix
6
251
• General Sound
Input Volume 50
Output Volume 50
Echo Canceller Disable
Audio Input Line In
• Sound Clip Upload 1
Sound Clip Name
• Sound Clip Upload 2
Sound Clip Name
• Sound Clip Upload 3
Sound Clip Name
• HTTP Server
Authentication Method Digest Authentication
HTTP Port 80
HTTPS Port 443
•SNMP Server
Use SNMP v1 and v2c Disable
Use SNMP v3 Disable
Administrator Contact Information
Administration Function Name
VB-R13VE/VB-R13
VB-R12VE
VB-M50B
VB-H652LVE
VB-H651V
Installation Location
Security Level No authentication and
no encryption
Authentication Algorithm MD5
Encryption Algorithm DES
• SNMP v1 and v2c Server
Community Name
• SNMP v3 Server
User Name
Security Level No authentication and
no encryption
Authentication Algorithm MD5
Encryption Algorithm DES
• FTP Server
Use FTP Server Disable
Item Setting
R13
M50
H652
H651
R13
R12
M50
H652
H651
User Name
•WS-Security
Check Time on Authentication Check
• Video Server
Maximum Number of Clients 30
Camera Control Queue Length 30
Maximum Connection Time (sec.) 0
Camera Control Time (sec.) 20
• Audio Server
Audio Transmission from the
Camera
Disable
Voice Activity Detection Disable
Audio Reception from Viewer Disable
• RTP Server
RTP Enable
RTSP Authentication Method Digest Authentication
RTSP Port 554
• Audio Multicast
Multicast Address 0.0.0.0
Multicast Port 0
Multicast TTL 1
• RTP Streaming 1
Video Size 480 x 270 JPEG*
Frame Rate 5
Multicast Address 0.0.0.0
Multicast Port 0
Multicast TTL 1
Audio Transmission Disable
• RTP Streaming 2
Video Size 480 x 270 JPEG*
Frame Rate 10
Multicast Address 0.0.0.0
Multicast Port 0
Multicast TTL 1
Audio Transmission Disable
• RTP Streaming 3
Video Size 480 x 270 JPEG*
Frame Rate 15
Multicast Address 0.0.0.0
* VB-M50B is set to 320x180 JPEG.
Item Setting
R13
M50 H652 H651
R13
M50
H652 H651
R13
M50
H652
H651
R13
M50
H652 H651
