Using Presets or the Home Position
It is possible to control the camera using a preset or home position registered to the camera in advance.
When you click the preset selection menu and select a preset from the list that is displayed, the camera will move to the
camera angle of the selected preset.
Clicking the [Home Position] button will move the camera angle to the home position.
Note
Register preset/home positions in advance in [Camera] > [Preset] > [Preset Registration] (P. 131) on the Setting Page.
The registered preset is displayed in the preset selection menu.
[Home Position] Button
Preset Selection Menu

Canon VB-R13 Specifications

General

Resolution	1280 x 960
Maximum Resolution	1280 x 960
Network Interface	10Base-T/100Base-TX
Sensor Type	CMOS
Image Sensor	1/3" CMOS
Angle of View	Diagonal: 82.4°
Minimum Illumination	0.1 lux
Minimum Illumination (Color)	0.3 lux (F1.6, AGC High)
Minimum Illumination (B/W)	0.1 lx
Video Compression	H.264
Audio Compression	G.711
Protocols	HTTP, HTTPS, TCP/IP, UDP, DHCP, DNS, NTP, RTSP, RTP, FTP, SMTP
Power Supply	PoE (IEEE 802.3af)
Power Source	DC 12 V, PoE (IEEE 802.3af)
Operating Temperature	-10°C - +50°C (14°F - 122°F)
Dimensions	Φ189 x 244 mm
Weight	Approx. 2.2 kg
Shutter Speed	1/1 - 1/10000 sec
Day/Night	Auto (ICR)
Frame Rate	30 fps
Operating Humidity	20% to 80% (no condensation)
Effective Pixels	Approx. 1.3 megapixels
