Carrier TRANSICOLD Vector 8500 User Manual

10–3 62-11640
1SVM ï BLACK
1
3
6
8
Component Terminal
SPï15 1
ESïD 2
DMï1 3
ESïC 4
SPï13 5
SPï16 6
SPï14 7
DMï10 8
Unused terminals: None
2SVM ï BLUE
1
12
24
35
Component Terminal
CSMVïA 2
CSMVïB 3
CSMVïC 4
CSMVïD 5
DP16ïN 6
DP16ïJ 7
DP16ïK 8
DP16ïL 9
DP16ïM 10
SPï17 11
DSïA 13
REMïA* 14
REMïC* 15
SPï18 22
DSïB 24
REMïB* 25
REMïD* 26
Unused terminals: 1, 12, 16 to 21, 23, 27 to 35
