CAS CAU Series User Manual

93
14.3.3.1 Communication speed settings
(1) The display changes from “io.b:****” to “b-300”.
Pressing the [CAL] key cycles through the available settings.
The stability mark (¨) appears, when the current setting is displayed.
Display during
setting
b-300 b-600 b-1200 b-2400 b-4800
Setting specifics
300bps
baud rate
600bps
baud rate
1200bps
baud rate
2400bps
baud rate
4800bps
baud rate
Display during
setting
b-9600 b-19.2K b-38.4K
Setting specifics
9600bps
baud rate
19.2Kbps
baud rate
38.4Kbps
baud rate
(2) When the desired setting appears, press the [O/T] key.
(3) Press the [POWER] key to return to “io.b: ****”.
14.3.3.2 Delimiter settings
(1) The display changes from “io.d: ****” to “d-Cr”.
Pressing the [CAL] key cycles through the available settings.
The stability mark (¨) appears, when the current setting is displayed.
Display during
setting
d-Cr d-LF d-CrLF d-Cn d-win
Setting specifics
delimiter
C/R
delimiter
L/F
delimiter
C/R + L/F
delimiter
Comma
delimiter
WindowsDirect
(2) When the desired setting appears, press the [O/T] key.
(3) Press the [POWER] key to return to “io.d: ****”.
14.3.3.3 Parity settings
The display changes from “io.P: ****” to “P-no”.
Pressing the [CAL] key cycles through the available settings.
The stability mark (¨) appears, when the current setting is displayed.
Display during
setting
P-no P-odd P-EvEn
Setting specifics
No parity
(eight bits)
Odd parity
(seven bits)
Even parity
(seven bits)
(1) When the desired setting appears, press the [O/T] key.
(2) Press the [POWER] key to return to “io.P:****”.
