CAS CAU Series User Manual

9
4
14.3.3.4 Stop bit settings
(1) The display changes from “io.S: ****” to “S-S1”.
Pressing the [CAL] key cycles through the available settings.
The stability mark (¨) appears, when the current setting is displayed.
Display during
setting
S-S1 S-S2
Setting specifics Stop bit, 1 bit Stop bit, 2bit
(2) When the desired setting appears, press the [O/T] key.
(3) Press the [POWER] key to return to “io.S: ****”.
14.3.3.5 Input-output data format settings
(1) The display changes from “io.F: ****” to “F-dF1”.
Pressing the [CAL] key cycles through the available settings.
The stability mark (¨) appears, when the current setting is displayed.
Display during
setting
F-dF1 F-dF2 F-dF3 F-dF4
Setting specifics
Data format 1.
Standard CAS
format.
Data format 2.
Extended
format from
data format 1.
Data format 3.
Same format
as Mettler
balances.
Data format 4.
Same format
as Sartorius
balances.
(2) When the desired setting appears, press the [O/T] key.
(3) Press the [POWER] key to return to “io.F: ****”.
When using EP-80, EP-50, EP-50WIN or EP-60A electronic printer,
always use data format 1.
When set to data format 2, the balance will always send a process result
in response to commands from the computer.
