CASE CONSTRUCTION CX17C - Moving the Unit; Machine Travel

4-OPERATINGINSTRUCTIONS
Movingtheunit
Machinetravel
WARNING
Controlscanbereversed!
Inthenormaltravelposition,theoperator'scompartmentisabovetheidlerwheelsandthetravel
reductiongearsaretotherearoftheupperstructure.Iftheupperstructureisturned180degreesin
relationtotheundercarriage,thecontrolsarereversed.
Failuretocomplycouldresultindeathorseriousinjury.
W0289A
WARNING
Hazardtobystanders!
Alwayssoundthehornbeforestartingthemachine.Makesuretheworkareaisclearofotherpersons,
domesticanimals,tools,etc.beforeyouoperatethemachine.Neverallowanyoneintheworkarea
duringmachineoperation.
Failuretocomplycouldresultindeathorseriousinjury.
W0304A
NOTE:increasetheenginespeedbeforeyoustarttrav-
eling.Inordertomaximizevisibility,fullyretractthearm
andcompletelyclosethebucket.
Selectionoftravelspeed
WARNING
Lossofcontrolhazard!
Avoidpressingthetravelspeedbuttonwhile
traveling.AvoidshiftingtoFASTspeedwhen
travelingdownhillorwhenloading/unloading
fromatrailer.
Failuretocomplycouldresultindeathorse-
riousinjury.
W0390A
Beforestarttraveling,makesuretoselecttheproper
travelmodebetween"Turtle"(slow)and"Rabbit"(fast).
Asthetravelmodeisselected,thetravelspeedvarieswith
thetiltingangleofthetravelcontrolleversandpedals.
NOTICE:duetohydraulicsystemcharacteristics,when
travelingandmovingarmsimultaneouslymachinemay
slightlydeviatefromintendeddirection.Payattention
whentravellingonslope,loadingorunloadingfromtruck
ortrailerorinotherconditionswithconnedlateralspace.
SMIL16MEX2340AB1
SMIL16MEX1499AA2
Travelalarm(optional)
Thetravelalarmisactivewhenthetravelalarmswitchis
turnedON.
Abuzzersoundscontinuouslywhenthemachinestarts
travelingforwardorbackward.
4-21
