CASE CONSTRUCTION CX17C - Dozer Blade Control Lever

3-CONTROLSANDINSTRUMENTS
Dozerbladecontrollever
WARNING
Hazardtobystanders!
ALWAYSmakesuretheworkareaisclearofbystandersanddomesticanimalsbeforestartingthis
procedure.Knowthefullareaofmovementofthemachine.Donotpermitanyonetoenterthearea
ofmovementduringthisprocedure.
Failuretocomplycouldresultindeathorseriousinjury.
W0245A
Thedozerbladecontrolleverislocatedontheright-hand
console.
Itcanbeusedtooperatethedozerbladeorthetrack
wideningframecontrolselectingoneofthetwopositionof
theswitch(1)whichenablestheoperatortooperatethe
dozerbladeorthecrawlertrackswidening.
SMIL17MEX3012AB1
SMIL16MEX2279AA2
