CASE CONSTRUCTION CX17C - Hydraulic Oil Level

6-MAINTENANCE
Hydraulicoillevel
WARNING
Burnhazard!
Beforeperforminganyserviceonthehydraulicsystem,youmustallowittocool.Hydraulicuid
temperatureshouldnotexceed40°C(104°F).
Failuretocomplycouldresultindeathorseriousinjury.
W0241A
Checkthehydraulicoillevelevery10horeveryday
Fluid:CASEAKCELAHYDRAULICLL46
1.Parkthemachineonaatandlevelplace,andarrange
theattachmentasshowninthegure.Stoptheengine,
andremovethestarterkey.
SMIL16MEX2502AA1
2.Openthedoorlocatedovertheright-handsideofthe
machinetoaccessthehydraulicoiltank(1).
Theoillevelisnormalifbetweentheredlinesofthe
levelgauge(3).
3.Ifthehydraulicoillevelisnotinthecorrectrangepro-
ceedasfollows:
•
Releaseallpressureinthehydraulictank.Referto
page6-10.
•
Cleanthecap(2)andtheareaaroundthecap.
•
Removethecap(2),andsupplyhydraulicuidtothe
hydraulicoiltank.
•
Installthecap(2).
NOTICE:makesurethatnocontaminant(water,sandetc.)
entersthereservoirduringlling.
4.Starttheengineafterllingandoperatetheworkequip-
mentseveraltimes.
5.Checktheoillevelafterenginestops.Closetheside
hood.
SMIL16MEX2657AA2
SMIL16MEX2658AA3
6-23
