8-SPECIFICATIONS
8-SPECIFICATIONS###_9_###
Dimensions
SMIL16MEX2536FA1
Operatingweight1700kg(3748lb)
(A)Overalllength3480mm(137.0in)
(B)Overallwidth,with230mm(9.1in)shoe990–1300mm(39.0–51.2in)
(C)Overallheight2320mm(91.3in)
(E)Overallheightofcanopy2320mm(91.3in)
(F)Groundclearanceofcounterweight440mm(17.3in)
(H)Minimumgroundclearance170mm(6.7in)
(I)Rear-enddistance645mm(25.4in)
(I’)Rear-endswingradius645mm(25.4in)
(J)Distancebetweentumblers1230mm(48.4in)
(K)Undercarriagelength1590mm(62.6in)
(L)Undercarriagewidth(extensioncrawler)990–1300mm(39.0–51.2in)
(M)Trackgauge(extensioncrawler)760–1070mm(29.9–42.1in)
(N)Trackshoewidth,standard230mm(9.1in)
(O)Heightofblade250mm(9.8in)
(P)Groundclearanceofbladeup285mm(11.2in)
(Q)Depthofbladedown225mm(8.9in)
Boomlength:1.80m(70.87in)
Armlength:0.96m(37.80in)
Withboomswingpost
