CASE CONSTRUCTION CX17C - Working Range Specifications

8-SPECIFICATIONS
Workingrange
SMIL16MEX2537FA2
(A)Maximumdiggingreach3900mm(153.5in)
(A’)Maximumdiggingreachonground3800mm(149.6in)
(B)Maximumdiggingdepth2200mm(86.6in)
(C)Maximumverticalwalldiggingdepth1320mm(52.0in)
(D)Maximumdiggingheight3580mm(140.9in)
(E)Maximumdumpingheight2570mm(101.2in)
(F)Minimumswingradius1570mm(61.8in)
Boomswingradius(left-hand/right-hand)
70°/54°
SAE
13.7kN(3079.9lb)
Bucketdiggingforce
ISO
15.5kN(3484.5lb)
SAE
8.3kN(1865.9lb)
Armcrowdforce
ISO
8.5kN(1910.9lb)
Boomlength:1.80m(70.87in)
Armlength:0.96m(37.80in)
Withboomswingpost
8-2
