6-MAINTENANCE

Whennecessary

Workinglights

Halogenworkinglights

1.Removethetworetainingscrews.

SMIL16MEX0939AA1

2.Extracttheworkinglight(1)anddisconnectthebulb

plug(2).

SMIL16MEX0935AA2

3.Pulltheclipoutwards(1)andremovethebulb(2).

SMIL16MEX0937AA3

6-66
